SHORT SET UP TIME
The compact dimensions and wide range of accessories of makes it easy to transport to the workplace. On site, it can easily be operated and configured as required.
DO MORE WITH ONE INVESTMENT
An IRONHORSE is a distinctive tool and transport carrier, allowing you to use it as a skinner, loader and pulling machine through its various attachments.
INCREASE YOUR REACH
The unique terrain characteristics allow you to access slightly more difficult areas with the same machine. Especially in wet areas, the benefits of belt drive are huge
CREATE SOMETHING UNIQUE
With Iron Horse as a platform, the customer has the opportunity to create a completely unique solution. We often help our customers to create their own accessory solutions that give them a great competitive advantage.
✓
Engine alternative: Honda iGX800, 25 hp(18.6kW)
✓
Transmission: hydraulic, variable (hydrostatic)
✓
Drive belt: internal drive with longer contact surface
✓
Working hydraulics: std 14.4 cm³, flow= 45 l/min, pressure=180+ bar
✓
Weight: 700 kg
✓
Load capacity: 1000 kg
✓
Dimensions: 194 x 114 x 117 cm (l x w x h)
✓
Remote controlled with radio control. Approximately 100 metres range.
✓
Traction: 1100 Kp
✓
Hydraulic radio-controlled winch Traction 800 Kg
✓
Engine four-stroke 9 Hp or 13 Hp
✓
With or without hydraulics
✓
Retractable control lever so you can ride on the machine
✓
Front/Back
✓
Handbrake
✓
Torque converter transmission
✓
Integrated motor winch
✓
Timber bunk
✓
Standard hand operated winch
✓
Chainsaw mount
✓
Storage box
✓
Differential lock
✓
Steel skid plate
✓
Heavy Duty rubber tracks with inside lugs
✓
Removable tooling point, mechanically or hydraulically
✓
Load capacity 1 ton
✓
Traction power 900 kp
✓
Speed 7 km/h
✓
Ground pressure 0.15 kg/cm³ at 500 Kg load
✓
Width 1080 mm
✓
Height 1120 mm (Transport mode)
✓
Length 1780 mm
✓
Weight 445 - 485 Kg
✓
Color Black or Green
✓
Option Hydraulics 21 litres/min Pressure 140 bar
The machine in the picture is equipped with a radio-controlled winch and dumper.
Also supplied with spreader blade and load protection plateover engine (not shown in picture)
✓
Weight 200 Kg
✓
Max load capacity 800 Kg
✓
Weight 30 Kg
✓
Speed 30 m/min
✓
Oil pressure 190 Bar
✓
Max traction 800 Kg
✓
Radio control 2 Channels
✓
Winch cable 6 mm
✓
Range Radio Approx. 50 m
✓
Winch cable length 25 m
